| Brand Name: | Tendars |
| Model Number: | Big tent |
| MOQ: | 25 square meters |
| Price: | Reconsideration |
| Packaging Details: | 1, The aluminium frame structure packed into the bubble film 2, the pvc fabric roof cover and sidewalls are packed into the PVC fabric carry bag; 3, Hardware packed into the box. |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
|
Frame |
4 channels, hard pressed extruded aluminium alloy 6061/T6. |
|||
|
(Surface anodized finish. Anti rust.) |
||||
|
Roof Cover |
water proof, 850g/m². Flame retardant.PVC-coated Polyester. |
|||
|
Wind Resistance |
80~140km/h |
|||
|
Snow Load |
25kg/sqm |
|||
|
Fixing Solution |
Ground anchor, expandable bolt, weight plate, etc. |
|||
|
Roof Insulation Material |
Heat insulation rate >60% |
|||
|
Drainage Waterproof Design |
Direct drainage or PVC rigid drainage pipe |
|||
|
Ground Situation |
Grassland,earth land,asphalt,cement ground,marble,etc |
|||
|
Connectors |
Hot-dip galvanized twin plate;expansion bolts to fix tent |
|||
|
Item |
Width |
Eave Height |
Ridge Height |
Bay Distance |
Main Profile |
|
DNPT |
6m |
2.6m |
3.48m |
3m |
100x48x3mm(4-channel) |
|
DNPT |
8m |
2.6m |
3.82m |
3m |
100x48x3mm(4-channel) |
|
ABT |
15m |
3.88m |
5.73m |
5m |
204x120x4mm(4-channel) |
|
ABT |
20m |
3.88m |
6.53m |
5m |
204x120x4mm(4-channel) |
|
ABT |
25m |
3.88m |
7.33m |
5m |
204x120x4mm(4-channel) |
|
AEBT |
30m |
3.92m |
7.87m |
5m |
256x121x5mm(4-channel) |
|
AHT |
40m |
3.92m |
9.60m |
5m |
300x120x5mm(4-channel) |
|
Customized size is available. |
|||||
Tents are designed with clear-span structures that offer a large, open interior without the need for internal support columns. The principle is to create a flexible and weather-protected environment suitable for hosting a wide range of sports, including basketball, tennis, volleyball, badminton, soccer, and more.
Sports Hall Tents typically feature durable materials such as steel frames and high-quality fabric covers that can withstand the rigors of sports activities and provide protection from the elements. The tents are often customizable to accommodate specific requirements, such as adjustable sidewall heights, lighting, flooring options, and branding opportunities.
The principle behind Sports Hall Tents is to offer sports centers and facilities a cost-effective and temporary solution for expanding their capacity or providing additional space for training, competitions, events, and recreational activities. These tents can be quickly installed and removed as needed, making them an ideal choice for seasonal sports, tournaments, or special events.
Q: Can you print our logos on the tent?
Yes. Customized logos can be printed on the tent fabric according to your requirements.
Q: Is that factory price?
Yes. We assure you all prices are based on factory.
Q: Does your tent be able to installed repeatedly? What is the life span?
Our tents can be assembled and dismantled easily and repeatedly with small transportation size. The lifespan of aluminium framework can reach 15-20 years, and 5-8 years for PVC fabrics depending on different conditions of usage.
Q: What documents are available?
A full range documents including structural drawings, packing list, installation manual and relative certificates can be provided. Moreover, customs declaration is provided. We provide one-stop service for you.
|
|
