| Brand Name: | Tendars |
| Model Number: | Small tent |
| MOQ: | 25 square meters |
| Price: | Reconsideration |
| Packaging Details: | 1, The aluminium frame structure packed into the bubble film 2, the pvc fabric roof cover and sidewalls are packed into the PVC fabric carry bag; 3, Hardware packed into the box. |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
|
Main Frame |
Hardpressed Aluminum Alloy T6061/T6 |
|
Roof |
850g/sqm white PVC coated Fabric |
|
Sidewall |
650g/sqm white PVC coated Fabric |
|
Available Width |
3-10m |
|
Length |
3-10m |
|
Height |
2.5-3m or customized |
|
Application |
Party, Event, Wedding, Exhibition |
1. Optional Size
3 - 6m (10 - 20ft) span option for different capacity and application.
2. Optional Sidewall
French windows, glass wall, ABS wall and sandwich panel are available in pagoda sidewall system.
3. Quick Installation
Chinese hat tent can be installed in a rapid manner by its modular and portable feature.
|
PAGODA TENT SPECIFICATION |
||
|
Main Profiles |
Material |
Hardpressed Extruded Aluminum Alloy T6061/T6 |
|
Available Size |
84 x 48 x 3mm |
|
|
Hardness Quality |
At Least 250 MPa |
|
|
Features of Frame |
Stainless, Lightweight, Durable, 4 Channel |
|
|
Windload |
Up to 100km/h |
|
|
Cover |
Material |
850g / sqm Block-out white PVC Tarpaulin, 950g / sqm transparent PVC Fabric; 650g/sqm White PVC for Sidewall |
|
Thickness |
≥0.67mm |
|
|
Features |
Best performances in breaking strength, water-proof, UV-proof, flame retardant (DIN4102 B1 M2 / NFPA701) |
|
|
Component |
Superior Enclosure with Hot Dip Galvanized Steel. |
|
Q1. What is the MOQ ?
One Set.
Q2. What is the Payment Term ?
30% Deposit to be made After signing PI, 70% before shipment.
Q3. What is the Normal Product Time for Standard Design?
15 - 25 days after deposit received.
Q4. Does Tenders Provide Basic Installation Tool?
We provide ropes to connect the PVC sidewall and fork for helping set up the frame.
Q5. Do You Provide Any Guidance on the Job-site?
We will attach the build instructions in your product package. If you need, we will send our technology staff and project manager to provide installation guidance in your job-site for FREE.
Q6. Where can I installed the Tent Structures?
Clear span tent structures can be installed without land permission and foundation unlimited. You can set up the tent on hard land, grassland, or sand land. Also, we will offer different fixation kit for your requirement.
|
|
