| Brand Name: | Tendars |
| Model Number: | Big tent |
| MOQ: | 25 square meters |
| Price: | Reconsideration |
| Packaging Details: | 1, The aluminium frame structure packed into the bubble film 2, the pvc fabric roof cover and sidewalls are packed into the PVC fabric carry bag; 3, Hardware packed into the box. |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
Width: from 3 meters to 50meters
Length: Unlimited, extended by 3m or 5m each bay
Eave height: standard from 2.5m, 3m, 4m to 5m upon span width (or special height per requested)
|
Type |
Span width |
Bay spacing |
Eave height |
Ridge height |
Main frame profile |
|
(m) |
(m) |
(m) |
(m) |
(mm) |
|
|
XDP-6 |
6 |
3 |
2.5 |
3.5 |
48X84X3 |
|
XDP-8 |
8 |
3 |
2.5 |
3.9 |
48x84x3 |
|
XDP-10 |
10 |
3 |
2.5 |
4.3 |
48X84X3/48x100x3 |
|
XDP-12 |
12 |
5 |
3 |
5.1 |
68x122x3 |
|
XDP-15 |
15 |
5 |
3 |
5.4 |
108X150X3 |
|
XDP-18 |
18 |
5 |
4 |
6.9 |
112X203X4 |
|
XDP-20 |
20 |
5 |
4 |
7.2 |
112X203X4 |
|
XDP-25 |
25 |
5 |
4 |
8 |
112X203X4 |
|
XDP-30 |
30 |
5 |
4 |
8.8 |
113X259X5 |
|
XDP-40 |
40 |
5 |
4 |
10.4 |
120X300X5 |
|
XDP-50 |
50 |
5 |
5 |
13 |
128x350x5 |
|
The length can be extended by 3m such as 6m,12,18m,30m... |
|||||
Frame struss: hard pressed extruded aluminium 6061/T6(15HW) which can last more than 15 years.
Fabric cover: high quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.
Connector: strong hot-dip galvanized steel
Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
Wind load: max.100km/h (can be reinforced)
Snow load: 25kg/sqm (snow can't stay if use big degree roof pitch design)
Easy to be assembled and dismantled, movable.
No pole inside, 100% available interior space.
1)White PVC cover(roof + sidewalls)
2)Clear PVC cover(roof + sidewalls)
3)White PVC wall with clear windows
4)Wall: Glass wall with windows, Sandwich walls, ABS walls, Steel panel walls
5)Door: glass door, metal door, shutter door, sliding door, etc
6)Flooring system
7)Lining and curtain
8)Other suppliers, such as door canopy, chairs, tables, lighting, air condition, etc
Custom design the tent according to the clients' requirements ,for example,higher height and unique shape .
we will set up every tent when we finish the production ,Installation video or pictures can be taken and must be sent to the client to check the quality and make payment of balance before delivery.
Installation manual /drawings can be provided for free if required,
Accessories can be provided at more favorable prices .
Frame can be working well for 10-15 years while fabrics for 6-8 years
1. Are you a Trading Company or Manufacturer?
We are a manufacturer specialized in Folding tents, Outdoor umbrellas, Beach flags, Advertising Banners;
2.Can you print any logo for customer?
Yes, both OEM and ODM is available;
3.Do you offer the free samples?
Sample is available but charged, but we promise to refund the sample fee once you place the bulk order.
4. How long does sample take?
Sample will be ready within 5-7 days, depends on your printing and material requirements.
|
|
