| Brand Name: | Tendars |
| Model Number: | Big tent |
| MOQ: | 25 square meters |
| Price: | Reconsideration |
| Packaging Details: | 1, The aluminium frame structure packed into the bubble film 2, the pvc fabric roof cover and sidewalls are packed into the PVC fabric carry bag; 3, Hardware packed into the box. |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
Aluminum Alloy Commercial Heavy Duty Marquee Waterproof Fire Retardant Tents For House
|
Item
|
Specification
|
|
Clear-span width
|
3m - 60m
|
|
Eave height
|
2.6m /3m/4m/5m/6m or customized
|
|
Ridge height
|
4.3 - 8m or customized
|
|
Roof pitch
|
20°
|
|
Longest component
|
3.7-10.6m
|
|
Minimum tent length
|
Can be customized
|
|
Roof fixing
|
Not limited
|
|
Main profile
|
84x48x3mm/ 122x68x3mm/ 166x88x3mm/ 203x112x4mm/ 204x112x4.5mm/ 256x120x5mm/ 300x125x5mm/ 350x126x6mm/ customized
|
|
Max.allowed wind speed
|
100km/hour ,0.5kn/m³ or can be customized
|
|
Eave/Ridge connection
|
Hot-dip Galvanized steel insert
|
|
Materials
|
(1) Frame structure: Hard pressed extruded aluminium 6061 /T6(15HW) which can last 15 to 25 years.
(2) Fabric cover: High quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc. (3) Connector: Strong hot-DIP galvanized steel |
|
Features
|
(1) Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
(2) Wind load: Max. 80km/h (can be reinforced) (3) Snow load: 75kg/sqm (snow can't stay if use big degree roof pitch design) (4) Easy to be assembled and dismantled, movable. (5) No pole inside, 100% available interior space. |
|
Optional accessories
|
(1) Covers: Colourful cover, transparent cover, inflatable roof cover
(2) Windows: Dome or square clear PVC windows, mesh window, glass window for glass wall (3) Wooden flooring system: VIP cassette flooring, simple cassette flooring (4) Doors: Double-wing glass door, single-wing glass door, glass fire door, aluminium door, rolling shutter(automatic or manual) (5) Wall: Soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall (6) Fixing methods: Ground anchors, weight plate, expandable bolts Rain gutters (inner roof beam rain gutter or rain gutter between two similar tents) (7) Other optional items: Table, chair, lighting, AC, carpet, installation tools etc. |
1. Advantage: competitive Advantage products.
2. MOQ:Sample offer & SMALL order welcomed .
3. Warranty period: Guarantee one year. During the warranty period, we shall repair or replace the damaged part accordingly
because of any damage due to quality problem.
4. Confidentiality agreement :"business secret contract".
5. Assurance:quality Assurance contract
The ventilation design of warehouse tents should consider the following aspects:
Roof ventilation: The roof of the warehouse tent should be equipped with appropriate skylights or vents so that it can be naturally ventilated in the case of high temperature or humidity, reduce the indoor temperature and humidity, and prevent the goods from being damaged by moisture or high temperature.
Side wall ventilation: The side wall of the warehouse tent can be equipped with openable windows or vents. When the outdoor air flows through, it can take away the moisture and heat in the room and keep the room dry and ventilated.
Ground ventilation: Appropriate drainage holes or vents should be set on the ground of the warehouse tent to discharge indoor moisture and heat in time and keep the room dry and ventilated.
The ventilation equipment of the warehouse tent mainly includes exhaust fans, ventilation ducts, filters, etc. Here are a few things to look out for when choosing a ventilator:
Air volume: Calculate the required air volume according to the warehouse area and environmental conditions, and choose the appropriate air volume.
Noise: Choose low-noise ventilation equipment to avoid disturbing the staff during use.
Energy consumption: Choose ventilation equipment with lower energy consumption to reduce operating costs.
Reliability: Choose ventilation equipment with reliable quality and stable performance to ensure the stability and reliability of long-term use.
Q: Can you print our logos on tent?
| Company: | Tendars technology Co.,Ltd |
| Address: | Room 904, No. 6, Hanxing 3rd Street, Zhongcun Street, Guangzhou, Guangdong, China |
| Contact person: | Amanda Chen |
| Tel: | 0086-13640286461 |
| Mobile(Wechat/Whatsapp): | +86 13640286461 / Amandachan8972 |
| Web: |
http://www.marquees-tent.com
|
|
